anechoic chamber.
An anechoic chamber absorbs all radio waves at the walls, ceiling, and floor. Measurements are performed in a greenāfield environment: the same reference conditions used by accredited test laboratories for official certifications.
This enables preācompliance measurements that are more accurate than required by standards. Fewer surprises during final certification, shorter development cycles, and faster timeātoāmarket.
What we do in the chamber
- Measure antenna radiation patterns in all directions (full 3D)
- EMC radiated emission testing: CE and FCC preācompliance
- Optimize antenna impedance using turntable measurements
- Identify interference between antennas, PCB components, and enclosure
- Compare design alternatives under identical, repeatable measurement conditions
Use our measurement chamber?
Comparing two antenna configurations can be done with us on the same day, in the same setup. At an external lab, you book again, pay again, and wait again.
EMC laboratory.
Extensive measurement equipment for radiated and conducted emission as well as immunity testing. We test actively during the design process: not as a final check, but as a feedback mechanism. EMC issues found early may cost a single day to fix. After market introduction, they can require a complete redesign.
Measurement equipment
- Spectrum analyser 9 kHz – 6 GHz
- EMC preācompliance receiver
- Conducted emission setup (LISN)
- ESD gun, burst/surge generator
ESD Protection
Both the development environment and the production floor are fully ESDāprotected: grounded workbenches, wrist straps and footwear, and controlled humidity. Electrostatic damage is subtle and unpredictable, a damaged component may function for years before failing unexpectedly.
Prototyping & Test Equipment
Soldering stations, hotāair rework, reflow oven, oscilloscopes, logic analysers, and RF power meters. Everything required for rapid prototyping and full validation. From schematic to working, validated prototype within a single environment.
